Fenix TK35R RED is a limited edition of the tactical flashlight Fenix TK35R. This flagship of the TK series provides you with a light output of up to 5800 lumens (ANSI) and the ability to cut through the darkness up to a distance of 610 meters. Behind this impressive power are four high-performance Luminus SFT-25R LEDs. In addition to the dazzling white light, the TK35R is also equipped with a powerful red light with an output of up to 260 lumens. Power is supplied by a pair of robust 18650 batteries, each with a capacity of 4000 mAh (included in the package), which you can conveniently recharge directly in the flashlight via a modern USB-C connector. Operation is intuitive and lightning-fast thanks to the tactical switch and the innovative FlexiSensa control toggle switch. This allows not only for locking out the flashlight to prevent accidental activation but also for choosing between white and red light. Need maximum runtime? On the lowest mode, the TK35R will light your way for up to 105 hours. The flat design, thanks to the side-by-side battery placement, ensures the flashlight fits perfectly in your hand and allows for a firm grip. Its robust, waterproof construction (IP68) is designed to withstand the harshest conditions, from downpours to extreme deployment. Whether you are a member of security forces, participating in rescue missions, engaged in hunting, or looking for an uncompromising companion for your outdoor adventures, the Fenix TK35R is ready to exceed your expectations.

All flashlight parameters (luminous flux, battery runtime, waterproofness, beam distance, and impact resistance) are measured in accordance with the ANSI/NEMA FL 1-2009 standard.

Fenix TK35R RED Flashlight Parameters

• Four high-performance Luminus SFT-25R LEDs and two red OSRAM GR QSSPA1.23 LEDs are used, all with a lifespan of 50,000 hours.
• A total of eight output modes:

  • Six white light modes: 5800 lumens (3 hours) -> 2000 lumens (3 h 15 min) -> 800 lumens (4 hours) -> 350 lumens (9 h 20 min) -> 30 lumens (105 hours) -> Strobe 3000 lumens
  • Three red light modes: 260 lumens (10.5 hours) -> 15 lumens (91 hours) -> Flashing 15 lumens
• Supports power from two 18650 Li-ion batteries. Two 18650 4000 mAh batteries are included.
• Max. battery diameter 18.6 mm, max. battery length 72.0 mm.
• Note: The runtime in the highest mode is stated including the gradual reduction of output due to overheat protection.
• Smooth reflector for a well-focused light beam with a beam distance of up to 610 meters (93000 cd) in white light.
• Red LEDs have a beam distance of up to 24 meters (150 cd).
• Digitally regulated output, overheat protection.
• The flashlight has a memory function and will always turn on in the last set mode for that color (does not apply to strobe).
• Switch for instant strobe activation.
• Reverse polarity protection to protect from improper battery insertion.
• Made of A6061-T6 aircraft-grade hard-anodized aluminum.
• Trapezoidal threads are highly resistant to wear.
• Durable, hard-to-scratch surface - Type III hard anodized.
• Impact resistant to drops from 1 meter.
• Waterproof according to IP68 standard (submersible to 2 meters for 30 minutes).
• Tactical switch on the tail of the flashlight (momentary on/off function).
• Dimensions 15.4 cm (length) x 4.3 (reflector diameter).
• Weight 342 grams (including batteries).
• Toughened ultra-clear glass lens with anti-reflective coating.
• The flashlight comes with a lanyard, 2x ARB-L18-4000 batteries, a holster, a USB-C charging cable, and a spare O-ring.

Using the Fenix TK35R Flashlight

From the factory, there may be an insulating cap on the battery. Remove it before first use.

With the rotary switch FlexiSensa Control on the tail of the flashlight, you can select the desired lighting mode: white light – locked – red light.

Turning On/Off - When the flashlight is unlocked, press the main tactical button on the tail to turn it on. For momentary activation, half-press the button.

Switching Output Modes and Strobe - By pressing the secondary function button, you can cycle through the output modes of the selected light color at any time during operation. The maximum mode of 5800 lumens can be directly activated at any time when the flashlight is unlocked by holding the main tactical button for 0.5 seconds. To switch to strobe mode while the light is on, hold the toggle button for 0.5 seconds. To turn the flashlight on directly in strobe mode, press and hold the toggle button.

Lockout/Off Mode - When the flashlight is on, in any state, turn the rotary switch to the Lockout/Off Mode to turn off and lock the flashlight. Pressing the buttons will then not be able to turn the flashlight on.

Last Mode Memory - The flashlight has a memory and will always turn on in the last used output level, except for strobe mode.

Changing Batteries - Unscrew the flashlight body and insert the batteries with the positive pole facing the head of the flashlight. Then, fully tighten the body again.

Charging - Slide the charging port cover on the tail of the flashlight, then connect the USB-C charging cable to the flashlight. The indicator in the toggle button will glow red during charging and will turn green when fully charged. If charging fails or the batteries are inserted incorrectly, the battery status indicator will flash red or remain off to alert the user to check the batteries. With a powerful 9 V/3 A USB adapter, fully depleted batteries will charge in 2 hours; with a 5 V/2.4 A USB adapter, they will charge in 4 hours.

Battery Level Indication - Each time the flashlight is turned on, the indicator LED in the toggle button will activate for three seconds. If the indicator LED is solid green, the battery is charged to more than 85%. Flashing green means 50-85% capacity. If it is solid red, it is charged to 25-50%. Flashing red indicates that less than 25% of battery capacity remains.

Low-Voltage Warning - If the battery voltage drops below a preset level, the flashlight will step down to a lower brightness level. After reaching the lowest output, the battery status indicator will start to flash red slowly to remind users to recharge or replace the battery in time.

Intelligent Overheat Protection - If the temperature of the flashlight exceeds 60 °C, the output will be automatically reduced. Once the temperature drops below 60 °C, the output will gradually increase again.

Warning

• Do not disassemble the sealed parts of the flashlight yourself, as this will void the warranty.
• Keep the flashlight out of the reach of children!
• Do not shine the flashlight directly into your own or anyone else's eyes!
• When using UV light, protect your eyes with glasses equipped with a UV filter.
• Never use batteries with different charge levels or different capacities.
• Lock the flashlight or loosen the body by a few turns to prevent accidental activation during storage or transport.
• If the protective rubber O-rings appear damaged after a long period of use, replace them. The rings should also be lubricated to prevent rubber erosion. By following these rules, the flashlight will be properly protected against water.
• If the flashlight flickers, does not switch to higher output modes, or does not turn on, it may be for one of the following reasons:
  • The batteries are nearly depleted – replace them.
  • The contacts inside the flashlight or battery holder are dirty – clean them with a cotton swab soaked in alcohol.
  • The flashlight body is loose – add lubricant to the sealing rings and tighten it.

Warranty

Five-year warranty on the flashlight, two-year warranty on the batteries.
